150 THE ENGINEERS SKETCH-BOOK. (3.) HYDRAULIC GEAR. See Section 42.The direct-acting plan is simply a ram and cylinder, as in thehydiaulic p?e.ss, the ram being as loiii; as the height of travel of tlie cage.For multiplying cylinder hydraulic gear, see Section 42. Balancing the dead load of cage,…
