ch the flow and return pipes fromthe furnace pass : the water becoming heated in thecistern flows out, and returns in the direction shownby the arrows. The flow pipe^ leaving this cistern,passes up to the expansion tube g, whence the tubesrun through the building in the manner shown,returning to… … should in reality contain two coils of pipe, having twoflows and two returns, the whole of which should gothrough the cistern/, but the small scale of the plateallows one circulation only to be shown. Dr. Aruotts principle of nearly equalizing tempera-tures was applied by hioi for room ventilation.…
