The essentials of gearing; a text book for students and for self-instruction, containing numerous problems and practical formulas (1911)
Anthony, Gardner C. (Gardner Chace), 1856- · Boston : D.C. Heath · leaf 134
GEAR 30 TEETH 1 PITCH INVOLUTE GEAR & PINIONSHOWING INTERFERENCE Plate lo. Plate 10. One Pitch Involute Pinion and Rack, showing Interference. IlEFEKENCES TO TEXT. Art. 42, Page 30.43, 32 AuT. 44, Puge 33.46, 35. … 1 PITCH INVOLUTE PINION i RACKSHOWING INTERFERENCE Plate II. Annular Gearing. REFERENCES TO TEXT. Art. 49, Page 38. Art. 52, Page 41. 50, 39. 54, 42. Plate 11Gearing
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
