The essentials of gearing; a text book for students and for self-instruction, containing numerous problems and practical formulas (1911)
Anthony, Gardner C. (Gardner Chace), 1856- · Boston : D.C. Heath · leaf 48
Fig. 10. 20 INTERCHAXGEABLE GEARS. … 91 4 D2 38 P 1.35 P. 32.3° 20.3°. Fig. 11. diameter being equal to one-half of the diameter of the pitchcircle. The form of the tooth ^vill now be E P F, and the pathof contact A P B. In the latter case the arc of contact willbe greater, the maximum angle of pressure less, and thetooth weaker than…
Gearing
