r/g. 2/^ F/g. 2/5 a soft packing of hemp, fiber, or leather is used. For large verticalengines steel pistons are sometimes used. Sliding Bearings. — Sliding bearings are of many forms, asshown in the following figures. The general end sought is tohave the projected area of slide such that the…
