ers, while for heavy planers it may be 110° or more.The side pressure of the tool must be considered in selecting theproper value of A since it exerts a tendency to raise the tablefrom the ways. MACHINE CONSTRUCTION 91 Fig. 214 shows the form generally used for lathe ways. It isself-adjusting, does…
