Hutton, Frederick Remsen, 1853- [from old catalog] · New York, J. Wiley & sons; [etc., etc.] · leaf 217
and lead are the given data. The angle AOBshows the advance of the eccentric disk beyond 90° properfor such lap and lead, and the cut-off takes place at an angleAOP ixowi the beginning of the stroke at dead-centre. Thedesign of a valve and its seat proper for the conditionsassumed will give a… … Fig. 141. surfaces of contact. Starting, therefore, at the point (9, whichmarks the extreme edge of the seat, a distance OB is laid offequal to the throw OB (Fig. 140), which is the radius of thevalve-crank, and the maximum distance it can throw from itscentral position. The point B will be the…
Mechanical engineering · Steam power plants
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
