n and thetop view of Fig. 347. 67. Space 5V2 X 1. Draw the top, front, and side viewsof a regular hexagonal prism.Fig. 348. Corners of hex 2V2.Height of prism V2. 68. Space 5V2 X 1. Drawthree views of the object shownin Fig. 349. 69. Space 5 V2 X T. Drawthree views of the object shownin Fig. 350.… … 148 ESSENTIALS OF DRAFTING
