bushing shown in Fig. 175, in section. Full size. 214. Space 11 x 14. Make an isometric drawing of themain casting of Fig. 175, in section. Full size. QUESTIONS, PROBLEMS, AND STUDIES 177 215. Make an isometric drawing of Fig. 195. Dimensions asfurnished by the instructor. i)l = [ ] i)2 = [ ] A = [… … Dimensions will be furnished by instructor. For forms of rivetssee Figs. 133, 134, and 135. 217. Space 5V2 X 7. Make an isometric drawing of theobject shown in Fig. 152. Scale 6 = 1 foot. 218. Space 5V2 X 1. Make a cabinet projection from Fig.152. Scale 6 = 1 foot. 219. Space 5V2 X 1. For scale of…
