us ; the objects may be drawn as a studyin still life, as, for example, in many of the figures illus-trating Deschanels Natural Philosophy (London, 1890)or they may be represented in a purely conventionalfashion. The latter is the better way, and it is preferableto draw for the most part in section… … Fig 35 75 RELIEF PRINTING It will be observed that all glass vessels and tubing arerepresented in section, and in the thermometers, the finecapillary bores are represented by a single line in eachcase ; corks by diagonal shading ; wood by lines inimitation of its grain ; metal parts by vertical…
