Smith, Leslie John, 1881- [from old catalog] · New York, The Macmillan company · leaf 67
dry, Coal chute, Drying clothes (in winter), Wood storage, Vegetable storage. Lighting equipment Fruit storage.(gas or electric lights), ^ Should the course in drawing not allow enough time for completeplans of a house, the first and second floor plans and basement plan mightbe worked out to a… … Figure ^5. SHORT COURSE IN DRAWING WITH INSTRUMENTS 57 The grading of drawings. — The three points to be consid-ered in grading drawings, are i, neatness; 2, lettering, figures,dimension and witness lines and arrows; 3, the actual draw-ings. A very good arrangement is to allow 10 points…
Mechanical drawing
