ry for transmittingthe energy received from the motor to a place where it can beusefully applied. 239. Water-pressure Engines.*—Water-pressure enginesare well adapted for use where a slow motion is required and agreat pressure is accessible. * See Weisbachs Hydraulics, Vol. II, p. 55S. 282… … Fig. 109.—Water-pressure Engine. nately forward and backward, water being admitted alternatelyat the two ends of the cylinder by the moving slide-valve S.While water is passing into one end of the cylinder throughthe passages D, E, C, it is being discharged through the pipeEy G, H, which is…
