Experimental engineering and manual for testing (1903)
Carpenter, Rolla C. (Rolla Clinton), 1852-1919 · New York, J. Wiley & sons; [etc., etc.] · leaf 486
Fig. 190.—^The Pantograph. point in the cross-head, its upper half moving vertically in aswinging tube. The cord is attached to an arc on this tube asin Fig. 188. 476 EXPERIMENTAL ENGINEERING. [§ 391. The pantograph, or lazy-tongs, as shown in Fig. 190, withplan of method of attachment shown in… … Fig. 191.—Method of Attaching the Pantograph. A form of pantograph with four joints only, shown in Fig.192, is much better adapted to high-speed engines than the onewith more numerous joints shown above.
