Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 219

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 219
a long sleeve sur-rounding the shaft and extending through the bearing into the casing.The set of three shifting pinions is shown in the position of slow for-ward speed. By moving them to the left the second and third speedsare engaged in succession, and after the gears of the third speed areout of…
