Experimental engineering and manual for testing. For engineers and for students in engineering laboratories (1906)
Carpenter, Rolla C. (Rolla Clinton), 1852-1919 · New York, J. Wiley & Sons; [etc., etc.] · leaf 693
e at the crank-pin due to the inertia ofthe parts. The instrument is shown in Fig. 290 attached tothe cross-head of an engine, and in Fig. 292 in plan. The frame P is rigidly attached to the cross-head A hy twostuds / and r, the former serving also as a pivot for the arm IJ.The upper end of B is… … Fig. agu— The Williams Inertia-instrument. Plan View.
