Experimental engineering and manual for testing. For engineers and for students in engineering laboratories (1906)
Carpenter, Rolla C. (Rolla Clinton), 1852-1919 · New York, J. Wiley & Sons; [etc., etc.] · leaf 698
Fig. 296.—Inertia-diagram. zero of acceleration, which of necessity corresponds with maxi«mum velocity, falls where it should. … Fig. 297.— Inertia-diagrams. All this is revealed in the same way in the experimentalinei lia-diagram Fig. 293, page 665, and the accuracy of the dia- 668 EXPERIMENTAL ENGINEERING. [§ 438. gram may be further tested by comparing the area below theneutral line with that above it by means of a…
