Experimental engineering and manual for testing (1903)
Carpenter, Rolla C. (Rolla Clinton), 1852-1919 · New York, J. Wiley & sons; [etc., etc.] · leaf 619
Fig. 237.—Inertia-diagram. zero of acceleration, which of necessity corresponds with maxi-mum velocity, falls where it should. … Scale 1=20 Force Units.1 ft. Strohe, 1 JRev, per Sec.Connectin(/ Ilod=0 Cranhs. Fig. 238.—Inertia-diagrams. All this is revealed in the same way in the experimentalinertia-diagram Fig. 234, page 603, and the accuracy of the dia- 6o6 EXPERIMENTAL ENGINEERING. [§ 438. gram may be further tested by…
Building materials · Machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
