Five hundred and seven mechanical movements (1903)
Brown, Henry T. [from old catalog] · New York, Brown & Seward · leaf 115
ding-pistons, <:, c^ to move in and out in obedi-ence to form of cam. Water enters and isremoved from the chamber through ports,L and M ; the directions are indicated byarrows. Cam is so placed that each pistonis, in succession, forced back to its seatwhen opposite E, and at same time… … Mechanical Movements. Ill 457. Common mode of raising water fromwells of inconsiderable depth. Counter-balance equals about one-half of weight to beraised, so that the bucket has to be pulleddown when empty, and is assisted in elevatingit when full by counterbalance. 458. The common pulley and…
