Vignola, 1507-1573, Juglaris, Tommaso, Locke, Warren S · [Boston, Press of Berwick & Smith] · leaf 107
tween centers of columns is 12 moduli, and the totalheight 25 moduli. The arch opening is 9 moduli wide and18 higli. The pilaster is 3 moduli wide —i of the width ofarch opening. The details will be comprehended from what has alreadybeen stated. The cap of the pilaster is 1 modulus high and… … PLATE XXV. ARCHED CORINTHIAN INTERCOLUMNIATIONWITH PEDESTAL, This modilicatioii of the Corinthian Order is spaced 16moduli on centers. The total height is 32 moduli. Of this, 7 moduli are forthe pedestal, 20 for the column, and 5 for the entablature.The arch opening is 12 moduli wide and 25 high.…
Architecture
