Vignola, 1507-1573, Juglaris, Tommaso, Locke, Warren S · [Boston, Press of Berwick & Smith] · leaf 91
ttle more than ^ of thecolumn. The height of the plinth is double its width. The heightis 5 moduli and 10 parts, with the fillets at top and bottom. The cap is 14 parts high, or \ of the total height of thepedestal, and projects 8 parts. The base is 12 parts high and projects 8 parts. The Base of… … PLATE XXI THE CORINTHIAN CAPITAL. YiGNOLA makes this Capital 2 moduli and 6 parts liigii.The bell is 2 moduli, and the abacus 6 parts high. Thesides of the bell are perpendicular 1 modulus and 10 partsfrom the bottom. The concave moulding of the bell is 6parts high and projects G parts, and the…
Architecture
