Buck, H. D. (Horace Davis) · New York, Bragdon, Lord & Nagle Company · leaf 123
movements is the shaft uponwhich the bevel gear (Figs. 75 and 81) is mounted and isdesignated by the number 9 in Figs. 75, 79 and 80. It may beplainly seen in the illustrations with its irregular surfacedcams which perform this work. Figs. 79 and 80 are views of the back of the machine, bothshowing… … Pig. 80.—Showing Hit- Jame Cam Shaft as Shown in Fi^End of the Machine. ro but from Left 122 FLAT MACHINE KNITTING AND FABRICS Mounting of the Deckers We will take up the manner of mounting the deckers andthe auxiliary parts through the medium of which the narrowingis done. Referring to Fig. 77,…
Machine knitting · Textile fabrics
