Buck, H. D. (Horace Davis) · New York, Bragdon, Lord & Nagle Company · leaf 21
e to make the propermovements to perform its functions. In this instance theyactuate the needles by coming in contact with the butts. It will be noted that each one of the needles from e to e,Fig. 16, has a loop in the hook except from the point where theyare rising over the cam a-3, and on these… … 20 FLAT MACHINE KNITTING AND FABRICS Now bear in mind that the cams a-1, a-2 and o-3, Fig. 16,are attached to the carriage b, b, b, b, Fig. 17, at points under-neath a-1, a-2 and a-3. These cams are moving from right toleft and as the lower left hand corner of a-3 is below the lineof the butts of…
Machine knitting · Textile fabrics
