Buck, H. D. (Horace Davis) · New York, Bragdon, Lord & Nagle Company · leaf 94
pposite one another, the cams a and h arenot. The bridges c and d have perfectly flat smooth surfacesexcept at points e and /, and here they have a concave portionabout one-eighth of an inch deep. The space between bridge c 92 FLAT MACHINE KNITTING AND FABRICS and cam k, also between bridge d and… … Under Side of Carriage With Cam System. Duljied Purl Stitch Machine. location of the cams a and b in relation to each other, and thebridges c and d with their concave spots e and /, in order tofully grasp their relation to the jacks and needles in theoperation of the machine. LINKS AND LINKS MACHINE
Machine knitting · Textile fabrics
