Modern locomotive engineering, with questions and answers .. (1913)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co · leaf 314
COMPOUND LOCOMOTWES 307 Ns\\^\\\\\\\m … xvwwwwv;- 3o8 LOCOMOTIVE ENGINEERING top quarter. Starting valve S closed, as in Fig, 146.Reverse lever in back motion. This admits steam from high-pressure steam chest E,through steam port D, to front end of high-pressurecylinder F. If steam now blows from back high-pressure cylindercock H, the…
Locomotives
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
