Kushlan, Max. [from old catalog] · Chicago, The Branch publishing company · leaf 25
outlined in the above two cases. This process, however, is rather tedious and requiresa lot of valuable time, so that in this free-hand work 20 FREE HAND DRAWING the students are not expected to perform their workin such a manner. The easiest and quickest way is to get the properamount of… … FIG. 16. Fig, 16, representing another arrangement of a cube,a cylinder and a square pyramid, will furnish addi-tional suggestions for arranging the models and forproper shading. The students are advised here tocarefully distinguish between the shades and shadowsin these figures. By the shade of a…
Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
