Fig. 35 is satisfactory if the right half is coveredwith paper, and the right half of Fig 36 is satisfactory if the lefthalf is covered : but neither drawing gives a satisfactory impression SCIENTIFIC PERSPECTIVE AXD MODEL DRAWING. 99 of the whole bureau. To do this the perspective, Fig. 37, must… … Fig. 34. Scientific Perspective (Paiailel). be parallel to parallel straight lines which extend on both sides ofthe spectator if they are to be satisfactorily represented. The station-point for Fig. 35 is about 352 from the paper andopposite a point near the top of the cut and over the left…
