Gas-engines and producer-gas plants; a practice treatise setting forth the principles of gas-engines and producer design, the selection and installation of an engine, conditions of perfect operation, producer-gas engines and their possibilities, the care of gas-engines and producer-gas plants, with a chapter on volatile hydrocarbon and oil engines (1905)
Mathot, Rodolphe Edgard, 1866- · New York N.W. Henley Pub. Co · leaf 220
ment hereshown (Fig. 107) seems to assure a proper engagement FIRE-BOX DOORS 221 of the joint surfaces. It consists of a yoke which strad-dles the door, and which, on the one hand, swings aboutthe hinge, and on the other hand engages a movablehoop. A screw, fastened to the yoke, serves to… … Figs. 107-108.—Fire-bo.x doors. need a tool may be introduced for^cleaning the grate.In this manner the grate may be cleaned withoutopening doors and without causing a harmful entranceof air. The door of the furnace, particularly, should be pro-vided with an iron counter-plate held by hinged…
Gas · Internal combustion engines
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
