The gasoline engine on the farm; a practical, comprehensive treatise on the construction, repair, management and use of this great farm power as applied to all farm machinery and farmer's work indoors and out .. (1913)
Putnam, Xenophon Whiting, 1867- · New York, The Norman W. Henley Pub. Co. · leaf 350
Fig. 113.—Bevel Gearing. either within the rim of the driven wheel, as in themain drive wheels of some mowers and of mosttractors, or around the outer side of the rim, as in … Fig. 114.—Intermittent Gears. most of the intermediate transmissions. Fig. iii il-lustrates the first type, and 112 the second. 447. Bevel and Miter Gears.—If the axes of a pairof gear wheels meet at an angle they are called bevelgears; if they meet at a right angle and the gears The Gasoline…
Internal combustion engines · Farm engines
