ired lettering, in the accustomedplaces. 33. Exercise II, Sheet II.—In Fig. 4, which occupiesthe whole sheet, we have an iron bracket, such as is used inmany cities as a sign hanger. It consists of straight andcurved iron rods bent into scrolls, combining beauty of curvewith utility of purpose. The… … §3 FREEHAND AND ORNAMENTAL DRAWING 39 tangent to the wall at g, \% below c. The branch scroll istangent to the wall at h, Z below c, and the other tangentpoints at i and j, \\ and 2f to the right of c, respectively.The other curves of the scroll, and the small ornamentalscrolls on the top and sides…
