Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing (1921)

International Correspondence Schools · Scranton, PA : International Textbook Co. · leaf 27

An illustration from Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing, 1921, leaf 27
should learnat the start to open and close them with one hand, holding 12 GEOMETRICAL DRAWING §1 them as shown in Fig. 26, with the needle-point leg resting between the thumband fourth finger, andthe other leg betweenthe middle and fore-finger. When draw-ing circles, hold thecompasses lightly atthe…

Architectural drawing · Geometrical drawing · Brush drawing · Perspective · Projection · Decoration and ornament

Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
