Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing (1921)

International Correspondence Schools · Scranton, PA : International Textbook Co. · leaf 377

An illustration from Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing, 1921, leaf 377
ELEMENTARY PERSPECTIVE DRAWING 87 as shown. It is not necessary that the ellipses represent-ing the plans of the columns be worked out entirely, as astraight line representing the diameter of the column at thebottom is all that is necessary. The rest can be done by eyemeasurement, and when the…

Architectural drawing · Geometrical drawing · Brush drawing · Perspective · Projection · Decoration and ornament

Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
