Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing (1921)

International Correspondence Schools · Scranton, PA : International Textbook Co. · leaf 463

An illustration from Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing, 1921, leaf 463
y to be less draft through this point.A simple panel isframed at the bottomof the upper sashshowing the interiorwhen the window isclosed; but when thissash is dropped down,the panel, which isframed upon the mul-lion, shows throughthe window and pre-sents a pleasing ap-pearance on the in-side. At… … Fig. 17

Architectural drawing · Geometrical drawing · Brush drawing · Perspective · Projection · Decoration and ornament

Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
