Steam engines, prepared in the Extension division of the University of Wisconsin (1919)
Shealy, Edward Marvin · New York, McGraw-Hill · leaf 54
<..rD-.in,.^ B Fig. 27b. shaped to conform to projections on the inside of the cylinderheads. Two examples of locomotive pistons are shown in Fig. 27. Inboth of these designs a special effort is made to secure strengthand Kghtness. The one shown at A is madeentirely of cast iron of a simple T…
Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
