Spanton, J. Humphrey (John Humphrey) · London, Macmillan and Co., Limited; New York, The Macmillan Company · leaf 115
nstruct within a given triangle ABC, and equidistant from the sides of it, a similar triangle, the base of which is equal to the given line D, Fig. 202.Bisect the angles BACand ACB by lines meet-ing at the centre E (Prob.12). Join EB. On theline AB set off AF equal tothe given line D. FromF draw a… … Fig. 202. Join KG. 102 GEOMETRICAL DRAWING AND DESIGN. 148. To construct about a given triangle ABC, and equidistant from its sides, a similar triangle, the base of which is equal to a given line L. Fig. 202. Set off on the base AB produced, AN equal to the given line L. From N draw a line parallel…
Geometrical drawing · Design · Drawing
