9. The plan is given (Q. 9) of a square prism, of which AB representsa square face, 3 each side. Determine the elevation of the prism onthe given xy, and add the elevation of a circular hole of 2 diameterpiercing the centre of the prism. 10, The diagram (Q. 10) shows a perspective sketch of part of…
