6o GEOMETRICAL DRAWING AND DESIGN. 91. To dra-w a circle which shall pass through the two givenpoints A and B and touch the given line CD. Join the two givenpoints AB, and producethe line till it meets thegiven line CD producedin E. On AE describethe semicircle EFA; at Bdraw BF perpendicular toAE.… … 92. To draw four equal circles, with radius equal to given lineE, to touch two given lines AB and CD, which are not parallel.
