United States. Patent Office · Washington, D.C., Govt. Print. Off. · leaf 250
S PETERS CO., PHOTO-LITHO.. WASHINGTON, D. C. I (No Model.) No. 494,807, E. E. FLORA. COIN OPERATED PHONOGRAPH. 3 Sheets—Sheet 3. Patented Apr. 4, 1893. … TMe NOflRlS PETERS CO. PHOTO-UTHO.. WASHINGTON. D. C United States Patent Office. ELLSWORTH E. FLORA, OF CHICAGO, ILLINOIS, ASSIGNOR TO GEORGE B. HOIT. COIN-OPERATED PHONOGRAPH. SPECIFICATION forming part of Letters Patent No. 494,807, dated April 4, 1893. Application filed May 5,1890. Serial No.…
Phonograph · Patents
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Graphophone patents], 1878, leaf 250](https://img.insideoutlibrary.com/img/1024/ia-graphophonepaten02unit-250-103.webp)
