United States. Patent Office · Washington, D.C., Govt. Print. Off. · leaf 572
ed diaphragm chamber forphonographs, comprising a central, cylindri-cal, longitudinal bore having its lower endflared, and a convex curved annular chambersurrounding thelower end of the central bore,substantially as and for the purpose specified. In testimony whereof I affix my signature in…
Phonograph · Patents
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Graphophone patents], 1878, leaf 572](https://img.insideoutlibrary.com/img/1024/ia-graphophonepaten02unit-572-245.webp)
