Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 118

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 118
INE ATOMIZER AND VAPORIZER. Hay type. The exhaust is used forheating the walls of the va-porizing chamber by trav-ersing the annular cham-ber e. A fan, //, is revolvedon the spindle, y, by the in-rushing air and gasolinethrough the valve E, whichalso covers the gasoline in-lets on the face of the… … 275. SOOT-PROOF SPARKING PLUG. For gas engine. Merger type. An annular pro-■r^M^ jection on the end of the por- celain insulator extends the insu-lating surface and prevents shortcircuiting of the electric spark.
