Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American Technical Society · leaf 276

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 276
ft, A?, at a point directly under the end of the stop-motion latch, Z’, which pro- jects through the rectangular slot in the support, H!. As the lifting shaft revolves, the cam is brought into contact with the lifter, forcing it upward against the underside of the stop-motion latch and lifting the… … against a collar, P*, which is fastened to the rod and which may be set to increase or decrease the tension upon the spring. ‘The free end of the spring rod passes through a hole in the support, and the other end is connected to the stop-motion latch. When the notch in the latch is clear of the…

Textile industry · Textile fabrics · Textile industry -- Encyclopedias · Textile fabrics -- Encyclopedias
