Information; elementary electricity, motor car electric systems, the gas engine from an ignition point of view, driving the car (1920)
Phillips, Harvey Elmer, 1874-1948 · Dayton, Ohio, Auto Electric Systems Publishing Company · leaf 158
g rate of the battery. This resistance wire is connected between pointsResistance and Meter. Wipe off controller blades occasionally with a clean cloth. THE MAGNETIC LATCH COIL This is nothing more than an ordinary solonoid magnet coil and is connected in serieswith the starting switch and the… … Adjustment of the Magnetic Clutch. The magnetic clutch arm U should be soadjusted by the adjusting screw Z that the arm T will pass the arm V, just allowing the pointsindicated by the arrows to clear each other when the main clutch is disengaged, and when themagnetic latch is in the disengaged…
Automobiles
Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
