The practical metal-worker's assistant : containing the arts of working all metals and alloys, forging of iron and steel, hardening and tempering, melting and mixing, casting and founding, works in sheet metal, the processes dependent on the ductility of the metals, soldering, and the most improved processes, and tools employed by metal-workers, with the application of the art of electro-metallurgy to manufacturing processes : collected from original sources, and from the works of Holtzapffel, Bergeron, Leupold, Plumier, Napier, and others ... (1851)

Byrne, Oliver · Philadelphia : H.C. Baird · leaf 209

An illustration from The practical metal-worker's assistant : containing the arts of working all metals and alloys, forging of iron and steel, hardening and tempering, melting and mixing, casting and founding, works in sheet metal, the processes dependent on the ductility of the metals, soldering, and the most improved processes, and tools employed by metal-workers, with the application of the art of electro-metallurgy to manufacturing processes : collected from original sources, and from the works of Holtzapffel, Bergeron, Leupold, Plumier, Napier, and others ..., 1851, leaf 209
it into the hollow tools employed, suchas Fig. 201; thus producing the same effect as in 203, but by stretch-ing the metal as we should the parchment of a drum, by the pressureof the hand in the centre, or by a blow of the drumstick. The solid blows around the three-inch margin, would thin themetal… … HOLLOWING. 205 position. Were the inner edge towards I, thinned beyond its dueamount, its expansion, if resisted by the strength of the outer ring a,would throw part of the work into a curve, and depress the metal,not as in the cymbal, but in the form of a gutter as in Fig. 205 ; itwould…

Metal-work · Electrometallurgy · Metallurgy

Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
