The practical metal-worker's assistant : containing the arts of working all metals and alloys, forging of iron and steel, hardening and tempering, melting and mixing, casting and founding, works in sheet metal, the processes dependent on the ductility of the metals, soldering, and the most improved processes, and tools employed by metal-workers, with the application of the art of electro-metallurgy to manufacturing processes : collected from original sources, and from the works of Holtzapffel, Bergeron, Leupold, Plumier, Napier, and others ... (1851)

Byrne, Oliver · Philadelphia : H.C. Baird · leaf 284

An illustration from The practical metal-worker's assistant : containing the arts of working all metals and alloys, forging of iron and steel, hardening and tempering, melting and mixing, casting and founding, works in sheet metal, the processes dependent on the ductility of the metals, soldering, and the most improved processes, and tools employed by metal-workers, with the application of the art of electro-metallurgy to manufacturing processes : collected from original sources, and from the works of Holtzapffel, Bergeron, Leupold, Plumier, Napier, and others ..., 1851, leaf 284
wire is respectively cut from two, three, or four equidistant partsof its circumference: semicircular cutters are also used. The straightcutters first named, are moreover very usefully employed in the fly-press for many of the smaller works, that would otherwise be donewith shears. Sometimes the… … nately, which are sometimes used, and the wires when inserted areslightly riveted at the ends. The pin is generally the weakest part of the chain and gives wayfirst, but in the chains with 8 and 9 links, the pin must be cut throughat 16 places simultaneously, before the chain will yield. Chains are…

Metal-work · Electrometallurgy · Metallurgy
