The practical metal-worker's assistant : containing the arts of working all metals and alloys, forging of iron and steel, hardening and tempering, melting and mixing, casting and founding, works in sheet metal, the processes dependent on the ductility of the metals, soldering, and the most improved processes, and tools employed by metal-workers, with the application of the art of electro-metallurgy to manufacturing processes : collected from original sources, and from the works of Holtzapffel, Bergeron, Leupold, Plumier, Napier, and others ... (1851)

Byrne, Oliver · Philadelphia : H.C. Baird · leaf 303

An illustration from The practical metal-worker's assistant : containing the arts of working all metals and alloys, forging of iron and steel, hardening and tempering, melting and mixing, casting and founding, works in sheet metal, the processes dependent on the ductility of the metals, soldering, and the most improved processes, and tools employed by metal-workers, with the application of the art of electro-metallurgy to manufacturing processes : collected from original sources, and from the works of Holtzapffel, Bergeron, Leupold, Plumier, Napier, and others ..., 1851, leaf 303
47, except that it is used as a fixture. The figure 347, just referred to, represents one variety of anothercommon form of the drill-stock, in which the revolving spindle isfitted in a handle, so that it may be held in any position without thenecessity for the breast-plate ; the handle is hollowed… … largest of the wires of which the drills are formed, and the hole ter-minates in an acute hollow cone. The end of the drill-stock is tappedwith two holes, placed on a diameter; the one screw, a, is of a veryfine thread, and has at the end two shallow diametrical notches; theother, 5, is of a…

Metal-work · Electrometallurgy · Metallurgy
