The carpenter's assistant : containing a succinct account of Egyptian, Grecian and Roman architecture. Also, a description of the Tuscan, Doric, Ionic, Corinthian and composite orders; together with specifications, practical rules and tables for carpenters, and a glossary of architectural terms. Embellished with upwards of 200 plates of plans, elevations, details, and practical stair-building (1854)
Brown, William, architect, Joy, Lewis E · Boston : Published by Edward Livermore · leaf 81
IONIC TEMPLE.Plate XI. On this plate is represented an Ionic Temple, merely to show thecontrast in the different styles of architecture, and to give the student themeans of discriminating, at once, between the several orders. This isdrawn to the same scale as the Doric Temple, Plate 7. 39 40 No. 9. … No. 9, as above, represents the side elevation of the same house, as seenm front elevation No. 7. The upper floor is shown in Fig. No. 10. (B) stair-landing, (a, e, p, k,)bed-rooms, (g) principal stairs, (h) passage, (c) dressing-room, or room forvarious purposes, (g) back stairs, (n) closet, (l)…
Carpentry · Architecture
