on. The ratio of the dimensions of Itsparts is exceedingly simple. It shouldbe noticed that the fillet below the cinc-ture of the shaft is included in theheight of the base of this Order. Theprojection of the cornice over the uppercircumference of the column is, in thisand in all Orders, except the… … UUUUUU F Plate III. Tlie Doric Order Is always effectivewhen used in lower storeys, arcades, anddoor and window openings, but owingto the triglyphs upon the frieze, whichmust fall centrally over the columns, itis the most difficult to deal with whenspacing is in question. The dimensions of the…
