ave openings in floorsand provide pipe shafts of proper size forthe work. In residences with wood studs the parti-tion carrying soil pipe must have at least 6studs and a still better arrangement is tohave a hollow space and use 4 or 6 studsflat wise and framed once or twice in theirheight as this… … Pressure Equalizing ValveShown above in black Lhis valve is a floating pistonwhich controls and equalizes thepressures of Hot and Cold Waterbefore they enter the mixingchamber. Prevents changes in 5temperature of shower caused byfluctuating pressures in supplylines due to the use of nearbyplumbing…
