on rod, and is connected to the weight bthrough a rod. The crosshead eliminates any tendency to bend thepiston rod that might result from the swinging of the point of attach-ment to the weight lever e. Over the crosshead guide is the floatinglever /. The point g of the floating lever is attached to… … ^Steam Inlet Fig. 8.—The floating lever. For the sake of clearness, let us assume that the motion of thethrust cylinders is to take the steps outlined below. As the operatormoves the lever d from the position x to the position y, the floatinglever is moved to the position indicated by the dotted…
