Handbook for machine designers, shop men and draftsmen (1916)
Halsey, Frederick A. (Frederick Arthur), 1856-1935 · New York, McGraw-Hill book company, inc.; [etc., etc.] · leaf 332
Fig. 24.—^Laying out vibrating levers. … •B \ Fig. 26. Figs. 25 and 26.—A problem in link work and its solution. Given the point 0 and the three positions OB, OC, and OD of anarm of known length swinging about 0; given the point Q and theangles b and c; required the length of the arm QR and the length ofthe link BR. Solution: Draw QB and…
Machine design
