w and one rivet in the outer row= iP-4d)tXT.S.+3XdXbXc.7 = strength of plate between rivet holes in the fourth row,plus the crushing strength of butt strap in front of four P. 103, p. 417. Figs. 13 and 14 illustrate other joints that may-be used. The butt and double strap joint with straps of equal… … Fig. II.—Butt and double strap joint,quintuple riveted.
